Carrello elevatore diesel LGSlifter FD80 da 8,0 tonnellate in vendita

Modello: FD80
Carico di sollevamento nominale: 8.0Tonnellata
Altezza di sollevamento libera: 100mm-150 mm
Power Engine: Diesel,Quanchai

The Diesel forklift, also known as carrello elevatore, is a Diesel motor-driven industrial carrello elevatore used for lifting and moving goods on a pallet within the premises of a warehouse, storage facilities and distribution centre.

It is avalibale for different industries using with LGS Carrello elevatore diesel.

LGS carrelli elevatori have different loading capacity , FD80 is 8.0 Tonnellata,FD100 is 10.0 Tonnellata.

1. Standard configuration LED energy-saving lamp, safety seat, wide vision mast, China Xinchai engine, IP56 protection grade electrical system, saving fuel and electricity.

2.The carrello elevatore is available with floating seats, a fully enclosed cab, air conditioning, heating.

And Japanese engines, American engines or any other engines that comply with US EPA emissions and EU standards are optional.

3.Diesel forklift used in factories, warehouses, stations, docks, airports, ports and other packaged goods Unloading and handling, when equipped with other working accessories, can also be used for bulk goods and other non-packaged goods Loading and unloading operations.

4.All the core parts of the forklift truck accept the warranty, no matter how long the use, can provide the replacement of the corresponding product accessories, accessories are complete, can be equipped with different forks and other industry requirements according to customer needs.

1.The engine is optional, according to the emission requirements of different countries. fully in line with international standards ISO and CE certification.

2.Narrow shape, conducive to entering the narrow aisle, turning radius is more flexible.

3.Full carrelli elevatori equipped with LED lights, longer lighting distance, longer use time.

4.LCD instrument panel design, full understanding of forklift conditions.

5.The engine fan is designed in, which is more convenient to improve fuel efficiency and accelerate air intake.

ModelloFD80FD100
Carico di sollevamento nominalekg80001000
Interasse del caricomm600
Altezza di sollevamento liberamm200
lunghezza complessiva ( Con forchetta/Senza forchetta )mm5175/39555497/4277
Larghezzamm2245
Altezza del tettuccio di protezionemm2570
Interassemm2800
Altezza minima da terramm250
Angolo di inclinazione dell'albero (anteriore/posteriore)%10°/12°
Pneumatico n. (Prima)9.00-20Sistema sanitario nazionale
Pneumatico n.(Dopo)9.00-20Sistema sanitario nazionale
Raggio di sterzata minimo (lato esterno)mm37554150
Larghezza minima del corridoio ad angolo rettomm57556010
Dimensione della forcellamm1520x170x701520X175X85
velocità massima di lavoro(A pieno carico/senza carico )km/ora20/26
velocità massima di sollevamento(A pieno carico/senza carico )mm/s330/350
massima pendenza superabile(A pieno carico/senza carico )%15/20
Peso del carrello elevatorekg1180012410
Modello del motoreQuanchai4J1-115C32
