FG25 FG30 2.5 Tonelada 3.0 Tonelada de carretilla elevadora/camión de gasolina de LPG
Modelo: FG25, FNG30, FG35
Carga de elevación con calificación: 2.5 Ton-3.5 Ton
Altura de elevación gratuita: 100mm-150 mm
Motor de alimentación: Diesel,Quanchai
- Descripciones de productos
Es avalibale para diferentes industrias utilizando con Lgslit LPG Máquina elevadora.
Lgslit montacargas tener una capacidad de carga diferente , FG15 is 1.5 Tonelada,FG20 is 2.0 Tonelada,and FG25 is 2.5 Tonelada.
1.LPG forklift truck adopts load sensing steering system to further improve working efficiency;Adopt fully closed instrument table and bottom plate to isolate chassis noise and reduce ear noise;
Gas Forklift equipped with buffer device, reduce the impact and vibration of the door frame, while improving the safety of operation;
2.Internal combustion forklift adopts suspension micro-braking mechanism and sunken inclined Gas forklift cylinder structure layout,
which greatly increases the space under foot.Using large arc structure to protect the top frame, expand the driving space;Hot air return
isolation device, optimized cooling duct, aluminum plate fin type water tank, improve the cooling capacity, ensure that the engine can By work.
3.Diesel Engine emissions meet the latest US EPA/CARB emission regulations.
Small wheelbase gasoline/liquefied gas counterweight forklift belongs to lifting and transportation machinery, widely used.
4.Perform loading, unloading and handling of packaged goods in factories, almacenes, estaciones, muelles, ports, etc.
After the equipment, it can also be used for the loading and unloading of unpacked goods and other packaged goods.



- Características de los productos
1.El motor es opcional, De acuerdo con los requisitos de emisión de diferentes países. Totalmente en línea con las normas internacionales de certificación ISO y CE.
2.Forma estrecha, propicio para ingresar al pasillo estrecho, girar el radio es más flexible.
3.Lleno montacargas Equipado con luces LED, distancia de iluminación más larga, Tiempo de uso más largo.
4.Diseño del panel de instrumentos LCD, Comprensión completa de las condiciones de montacargas.
5.El ventilador del motor está diseñado en, que es más conveniente para mejorar la eficiencia del combustible y acelerar la ingesta de aire.
- Especificaciones del producto
Carretilla elevadora de GLP | |||||||||||||||||||
Specifications | |||||||||||||||||||
1 | Manufacturer | ||||||||||||||||||
2 | Modelo | FG15 | FG20 | FG25 | FNG30 | FG35 | |||||||||||||
3 | Power type | GAS | |||||||||||||||||
4 | Rated capacity | kg | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | |||||||||||
5 | Centro de carga | mm | 500 | ||||||||||||||||
6 | Operator type | Drive seat | |||||||||||||||||
Size | |||||||||||||||||||
7 | Max. lift height of mast with Load-backrest | mm | 4030 | 4030 | 4030 | 4262 | 4262 | 4275 | |||||||||||
8 | Max.lift height of fork | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | |||||||||||
9 | Height of mast | mm | 1985 | 2000 | 2000 | 2065 | 2180 | 2150 | |||||||||||
10 | Free lift height(with backrest) | mm | 125 | 170 | 170 | 160 | 170 | 150 | |||||||||||
11 | Height of Load-backrest | mm | 1010 | 1010 | 1010 | 1240 | 1235 | 1235 | |||||||||||
12 | Distance from seat to overhead guard | mm | 1015 | 1000 | |||||||||||||||
13 | overhead guard height | mm | 2070 | 2070 | 2070 | 2090 | 2090 | 2105 | |||||||||||
14 | Length without fork | mm | 2230 | 2502 | 2576 | 2682 | 2693 | 2895 | |||||||||||
15 | Voladizo delantero | mm | 420 | 477 | 477 | 479 | 498 | 500 | |||||||||||
16 | Rear overhang | mm | 424 | 420 | 494 | 495 | 495 | 495 | |||||||||||
17 | Wheel base | mm | 1400 | 1600 | 1600 | 1700 | 1700 | 1900 | |||||||||||
18 | The height of traction pin | mm | 230 | 290 | 290 | 310 | 310 | 330 | |||||||||||
19 | Min. ground clearance | mm | 100 | 110 | 110 | 135 | 135 | 130 | |||||||||||
20 | Ancho general | mm | 1070 | 1170 | 1170 | 1225 | 1225 | 1410 | |||||||||||
21 | The distance between forks | mm | 910/125 | 1024/200 | 1024/200 | 1060/250 | 1060/250 | 1290/260 | |||||||||||
22 | Tread(front /rear) | mm | 890/920 | 970/970 | 970/970 | 1000/970 | 1000/970 | 1160/1065 | |||||||||||
23 | Min. Turning radius(outside) | mm | 2060 | 2170 | 2240 | 2400 | 2420 | 2700 | |||||||||||
24 | Min. Turning radius(inside) | mm | 130 | 160 | 160 | 200 | 200 | 230 | |||||||||||
25 | Min. Intersecting aisle | mm | 1865 | 2200 | 2280 | 2380 | 2400 | 2685 | |||||||||||
26 | Ángulo de inclinación de mástil | deg | 6° / 12° | ||||||||||||||||
27 | Tamaño de la bifurcación | mm | 920X100X35 | 920X100x45 | 1070X100x45 | 1070X125x45 | 1070X125x50 | 1070X130X50 | |||||||||||
Control device for driving and transmitting | |||||||||||||||||||
42 | Batería | V/AH | 12/80 | 12/80 | |||||||||||||||
43 | Engine (standard) | Modelo | Japanese Engine K25 | 4Y Model | |||||||||||||||
44 | Rated output | kw/rpm | 37/2800 | 43/2800 | |||||||||||||||
45 | Rated torque | N.m/rpm | 154/1800 | 163/1800 | |||||||||||||||
46 | No.of cylinder | 4-91X86 | 4-91X86 | ||||||||||||||||
47 | Displacement | L | 2.448 | 2.237 | |||||||||||||||
48 | Fuel tank capacity | L | 60 | 60 | |||||||||||||||
49 | Number of speeds for transmission | power pallet transmission |
